C.R.Plastic Products L38 User Manual

Page 2

Text mode
Original mode

A. Left Arm Qty: 1

B. Right Arm Qty 1

C. Rear Stringer Qty: 1

D. Front Stringer Qty. 1

E. Back Qty. 1

F. Back Support Qty. 1

G. Seat Qty. 1

H. Front Legs Qty. 1

PARTS LIST:
A Left Leg
B Right Leg
C Rear Stringer
D Front Stringer
E Back
F Back Support
G Seat
H Front Legs

HARDWARE LIST:

16 Screws 1-1/2”
8 Bolts
8 Nylock Nuts



Note:

Read these instructions carefully before assembling.
Tools required: # 2 Phillips or #2 Robertson bit a power drill and two 7/16” wrenches.
Find a clean, smooth area on which to work, such as a carpet, in order to avoid scratching the plastic surfaces.
Two people might be required for assembly.
Caution! Do not over tighten screws.
