Effective Date: 5/98 RDR 2000 Pilot's Guide: Rev 3
63
Maximum Permissible Exposure Levels (MPEL)
In order to avoid the envelope in which the radiation level exceeds the
U.S. Government standard of 10 mW per square centimeter, all per-
sonnel should remain beyond the distance indicated in the illustration
below. The distance to the MPEL boundary is calculated upon the basis
of the largest antenna available with the RDR 2000, rated output power
of the transmitter and in the non-rotating or boresight position of the
antenna. With a scanning beam, the power density at the MPEL
boundary is significantly reduced.
Appendix
MPEL BOUNDRY
120°
10 FEET
RADOME
OF AIRCRAFT L
C
