KSN 765/770 Integrated Communication Navigation Display Pilot QRG
Page 36 D200909000026
REV 2 Jun 2014
5. Select the desired parameter field by moving the
joystick up or down or by pushing the touchscreen on
the desired field.
6. Toggle the joystick knob to select and modify hold
parameters as desired.
NOTE: When published hold specifications are
modified, the PUB bezel softkey label is
displayed. Pushing the PUB bezel softkey
populates fields with published values.
7. Push the OK bezel softkey when the hold parameters
are set as desired.
The hold is entered into the flight plan. Note that HLD
is displayed next to the holding waypoint in the
waypoint list, and
HLD is displayed under the
waypoint name in the text data field.
Hold Entered Into Flight Plan
