KSN 765/770 Integrated Communication Navigation Display Pilot QRG
D200909000026 Page 19
REV 2 Jun 2014
EDIT A FLIGHT PLAN
The following pages describe how to edit a flight plan.
Connect a WPT Disconnect
A disconnect is created whenever a defined path does
not exist between two waypoints. For example, adding a
procedure may result in a disconnect in the flight plan.
When
a disconnect exists in the flight plan,
WPT DISCONNECT is displayed in the waypoint list.
In order to remove the disconnect, push the Direct-To
key (
D ) and select a waypoint after the disconnect
message, or complete the following procedure:
1. Push the disconnect message twice to highlight the
disconnect in the Waypoint List window.
