Rev 2
KTA 870/KMH 880 Pilot’s Guide Additional EGPWS Information
006-18265-0000
58
Table 2: Alternate Voice Callout Menu
Note 1: These are the only voices that can interrupt.
Note 2: The preface voices will always be given prior to the warning
voice.
Note 3: Voice message is continuous.
Note 4: Voice message will repeat every 7 seconds.
Note 5: This callout is optional.
GA-EGPWS COCKPIT LAMPS & SWITCHES
A representative sample of a possible annunciator and switch installation
is pictured below. Other configurations are at the discretion of the
installer and operational requirements of the aircraft.
Typical Annunciator
GA-EGPWS SYSTEM LIMITATIONS
* The GA-EGPWS is a Situational Awareness tool, and an alerting and
warning device. It is not to be used for navigation of the aircraft.
* The GA-EGPWS must have an operating source of GPS information,
with enough satellites in view to provide GPS data within the accuracy
requirements of the system.
* Without the optional Outside Air Temperature (OAT) input for correc-
ALERT/WARNING CONDITION
PULL UP
TERRAIN AWARENESS PREFACE
TERRAIN AWARENESS WARNING
OBSTACLE AWARENESS PREFACE
OBSTACLE AWARENESS WARNING
TERRAIN AWARENESS CAUTION
OBSTACLE AWARENESS CAUTION
RFCF TOO LOW TERRAIN
ABOVE FIELD CALLOUT
SINK RATE
DON’T SINK
ALTITUDE MONITOR CALLOUT
AUDIO MENU
PULL UP
TERRAIN TERRAIN
PULL UP
OBSTACLE OBSTACLE
PULL UP
CAUTION TERRAIN (PAUSE) CAUTION TERRAIN
CAUTION OBSTACLE (PAUSE) CAUTION OBSTACLE
TOO LOW TERRAIN
500
SINK RATE
Note: The basic warning is “SINK RATE (PAUSE) SINK RATE”.
However, if the Pull-up curve is violated only a single “SINK
RATE” may occur prior to the pull up voice.
DON’T SINK (PAUSE) DON’T SINK
CHECK ALTITUDE
NOTES
1
1, 2
1, 3
1, 2
1, 3
4
4
5
EGPWS
NOT
AVAIL
TEST
ALERT INHIBIT CAUT
WARN
