BendixKing KFC 500 - Manual (Page 66)

61
Go-Around Pitch Up Command Pitch to 750 fpm Climb
Alt Sel Engage Range 0 to 55,000 Ft.
Engage Vert Spd Limit Function of Vert. Speed
Max “G” During Capture
± 0.1G
Alt Hold Engage Range -1,000 to 20,000 Ft.
Engage Vert Spd Limit ± 2,000 Ft/Min
Accuracy ± 40 Ft*
Pitch Rate Limit 0.1G Vert Accel
IAS Hold Engage Range 50 Kts to VMO
Accuracy ± 3 Kts
Pitch Rate Limit 0.1G Vert Accel
Vert Spd Engage Range +10,000/-15,000 Ft/Min
Accuracy ± 100 Ft/Min*
Select Range ± 7,000 Ft/Min
Pitch Rate Limit 0.1G Vert Accel
Flight Director Pitch Command Limit +15 Deg, -10 Deg
Autopilot Pitch Engage Limit +25 Deg, -20 Deg
All accuracy specifications are based on aircraft operations in smooth air.
* Indicates altitude below 9,000 Ft. MSL.
Mode Parameter KFC 500 Value
