Controls
Time Set
Daylight Saving Time Switch
Home / World Time Selection
Loudspeaker
Freq – Allows direct frequency input
Single Side Band (SSB) / RDS / Alarm mode
LCD display
Standby / Sleep timer
LED charge indicator
Backlight
Squelch
Rotary tuning knob – Edit characters selected /
Frequency adjustment / Home-world city selection /
SW page selection
Step – Station frequency spacing
Tuning Up Down button – Manual tuning / Auto tuning /
Page selection / Edit / Home-world time search
Lock switch (Locks all settings)
Edit / Create station name, home/world city name and page name
Priority – Instant recall favorite station
Page selection: 3 pages FM, 2 pages MW, 1 page LW,
39 pages SW
Enter selection
Memo – allows memory input
Selection cancel / SW 11 meter band
Digit input / Clock / Memory & SW meter band / Edit
Decimal point / SW 15 meter band / Edit
ATS / LW – Selects LW band / Presets all stations
METER / SW – Selects SW band
ATS / MW – Selects MW band / Presets all stations
ATS / FM – Selects FM band / Presets all stations
Timer – Alarm timers (1,2,3)
Aux-in switch
AM RF gain – Adjusts level of incoming signal to prevent overload
1
2
3
4
5
17
6
7
8
9
10
11
12
13
14
15
16
19
20
21
22
23
24
18
25
26
27
28
29
30
4 5
