Call States
As
a
call
progresses
from
beginning
to
end,
it
goes
through
a
number
of
defined
stages
known
as
Call
States.
The
following
call
states
are
defined
for
calls
on
the
OBi:
Icon
Call
State
Description
Available
Operations
LED
Pattern
Dial
Tone
Dial
tone
is
played
to
prompt
user
to
enter
the
target
number
to
call
End
Steady
green
Dialing
User
is
entering
a
target
number
to
call
End
Steady
green
Trying
Trying
to
call
the
dialed
number
but
the
called
party
has
not
started
ringing
yet
End
Steady
green
Peer
Ringing
The
called
party
is
ringing
End
Fast
blinking
green
Ringing
An
incoming
call
is
ringing
the
phone
Reject,
Answer
Fast
blinking
red
Connected
Connected
on
a
call
and
both
sides
are
talking
End,
Hold,
Transfer,
Blind
Transfer
Steady
green
Holding
User
has
placed
the
call
on
hold
End,
Resume,
Add
to
Conf.,
Transfer,
Blind
Transfer
Slow
blinking
red
Ended
Call
failed
due
to
various
reasons,
such
as
invalid
number,
service
not
available,
called
party
busy,
etc.
End
(Remove
the
Call)
Slow
blinking
green
Idle
No
Call
-­‐
Off
There
are
many
operations
that
may
be
applied
to
a
call
-­‐
for
example,
holding,
resuming
or
ending
a
call
are
commonly
used
operations.
The
options
to
manipulate
a
call
are
typically
presented
to
the
user
as
soft
key
options,
while
the
most
frequently
used
call
operations
can
also
be
mapped
to
a
feature
key
-­‐
such
as
the
Hold
and
Transfer
functions.
Soft
key
options
are
call
state
sensitive,
only
the
options
that
are
applicable
to
the
call
at
its
current
state
are
shown
and
as
the
call
transitions
from
one
state
to
another,
the
soft
key
options
on
the
screen
will
be
updated
accordingly.
This
will
be
discussed
further
in
the
“Calls
App” section.
As
detailed
in
the
section
titled
“Call
Keys”,
each
call
on
the
phone
must
be
assigned
to
a
call
key
and
each
call
key
has
its
own
VLKW
on
the
screen
that
is
displayed
next
to
the
line
key.
To
help
the
user
identify
the
current
state
of
a
call,
each
call
state
is
represented
by
a
distinct
icon
that
is
shown
in
the
respective
VLKW.
Furthermore,
the
LED
of
each
call
key
stays
steady
or
blinks
with
a
certain
pattern,
indicating
the
current
call
state.
Making Basic Calls
With the Handset
Lifting
the
handset
from
the
cradle
will
start
the
dial
tone
and
display
the
Dial
Dialog
on
the
screen.
The
following
figure
shows
a
dial
dialog
ready
for
the
user
to
enter
a
number.
