OFNA Racing Mutilator Power Start - Manual (Page 26)

0
5 10 15 20 25 25 20 15 10 5
49 ASSEMBL OF THE WING Y
........x2 94041
3mm
Nylon Nut
........x2 94004
3x12mm
Hex Screw
50 MOUNTING BODY
51 STARTING OF THE ENGINE
31159
*Check the hole spacing on the underside.
1.Connect the Starter to the truck
*Follow the engine manufacturer instruction
manuals regarding engine set-up, carburetor
and maintenance.
How to start the engine:
40083
3x12mm
40027
3mm
40673RW
*Connect the Starter control box to the connector
located in the rear shock stay mount.
*Caution : Before starting the engine ,review the
important-read this before running and operate
your model safety.
2.Start the engine
*With one hand ,hold the throttle half open using
the throttle trigger on the transmitter. With your
other hand ,press the red button on the Starter.
If the engine does not start ,release the red
button and try again in 5 sec. Interval.
Electric Starter
7.2V Battery
(Not included)
Electric Starter
