46 assembl of the rear shock absorber y – OFNA Racing Mutilator Power Start User Manual
Page 25
3x8mm
3mm
3x20mm
46
ASSEMBL OF THE REAR SHOCK ABSORBER
Y
Assembly for both right and left side
........x2
94041
3mm
Nylon Nut
........x2
94007
3x20mm
Hex Screw
47
ASSEMBL OF THE TIRES AND WHEELS
Y
48
ASSEMBL TIRE ONTO FRONT KNUCKLE AND REAR HUB
Y
Step 1
Step 3
Step 2
IN
S
T
T
A
N
G
L
U
E
Apply instant glue into the groove of the wheel.
81106
80022
86106
........x2
94040
3x8mm
Washer
40550
Tire and wheel assembly
