OFNA Racing Mutilator Power Start - Manual (Page 19)

40136
(120mm)
40136
(104mm)
3x10mm
4x10mm
3x10mm
29 ASSEMBL OF THE CENTER DIFF. ONTO CHASSIS Y
30 ASSEMBL OF THE RADIO TRAY ONTO CHASSIS Y
........x4
4x10mm
Flat Head
Hex Screw
........x8
94019
3x10mm
Flat Head
Hex Screw
Radio Tray assembly
31 ASSEMBL OF THE FUEL TANK ONTO CHASSIS Y
........x2
94019
3x10mm
Flat Head
Hex Screw
........x2
94004
3x12mm
Hex Screw
Do Not
Over Tighten
*Insert the drive shaft into
the cap joint before assembly
center diff. onto chassis.
Step 2 Step 1
Pressure Nipple
40138
Pressure Nipple
3x12mm
40109
........x2 94040
3x8mm Washer
3x12mm
3x8mm
3x8mm
