Page 11

background image

........x2

........x2

........x2

Makes two rods for left and right
hand-side.

10

ASSEMBL OF THE FRONT STABILIZER

Y

9435
3x8mm
Set Screw

30403
6mm
Ball

94006
3x18mm
Hex Screw

........x2

........x4

11

ASSEMBL OF THE FRONT STABILIZER

Y

94003
3x10mm
Hex Screw

94033
3x3mm
Set Screw

Assembly for both right and left side

30341

40029

30403

3x8mm

40199

12

ASSEMBL OF THE SERVO SAVER

Y

........x1

94004
3x12mm
Hex Screw

........x2

94009
4x10mm
Hex Screw

40037

40031

40032

40031

40031

40031

40035

40031

40031

40621

40034

4x10mm

40036

3x12mm

40030

40018

40037

*Do not tighten 40037
Hex Screw too tight.

*Take the plastic bushing from servo
saver plastic parts tree.

4x10mm

Step 1

Step 2

3x18mm

3x10mm

40017

40017

40019

3x3mm

3x3mm

Screw

Cement

Sc

rew

t

Ce

me

n

*Approx. 6mm
