31

32

ASSEMBLY OF THE REAR BUMPER

ASSEMBLY OF THE REAR BUMPER

33

MOTOR INSTALL

40944

3x18mm

3x10mm

3x10mm

94003
3x10mm
Hex Hex Screw

.....x6

94006
3x18mm
Hex Hex Screw

.....x2

3x10mm

11

Step 1

Step 2

94056
3x12mm
Cap Screw

.....x2

3x7x0.5mm

4x4mm

30669
Adaptor 5 to 3 mm

94034
4x4mm
Set Screw

.....x1

30664-13 (13T)

40936

40965
12T

Brushed Motor

(550 Size)

40944

3x12mm

Assemble both right and left sides.

3x7x0.5mm
Washer

.....x2

40963
