Page 23

background image

17

Step 2

46

ASSEMBLY OF THE REAR BUMPER

.....x2

36870
4x10mm
Set Screw

4x10mm

31159

40720

31159

40117

2.6x15mm

2.6x15mm

2.6x15mm
Screw

.....x2

94026
4x12mm
Flat Head
Hex Screw

.....x2

40721

Tighten

Tighten

Step 1

47

94009
4x10mm
Hex Screw

.....x2

4x10mm

3x12mm

94004
3x12mm
Hex Screw

.....x2

ASSEMBLY OF THE REAR BUMPER

*The 4x10mm set screw is used to adjust down stop.

*Approx. 3 mm

48

ASSEMBLY OF THE AIR FILTER

38400
Air Filter

*Apply filter oil to the foam before use.

40720

40117

40117

4x12mm
