Assembly of the front bumper – OFNA Racing DM-1 Spec RTR User Manual

Page 21

background image

15

41

ASSEMBLY OF THE RADIO TRAY ONTO THE CHASSIS

ASSEMBLY OF THE STEERING ROD INTO SERVO

40

30401

*Use the screw provided
with your servo.

3x3mm

10300

*Snap on.

30411

30661

30661

38280

3x12mm

*Approx. 17.8mm

1:1

.....x2

.....x1

94004
3x12mm
Hex Screw

30401
Plastic Ball End

.....x1

94005
3x16mm
Hex Screw

3x10mm

3x16mm

3x10mm

.....x8

94003
3x10mm
Flat Head
Hex Screw

.....x1

94033
3x3mm
Set Screw

30401

30411

.....x1

94041
3mm
Nylon Nut

4x12mm

ASSEMBLY OF THE FRONT BUMPER

40721

40721

94026
4x12mm
Flat Head
Hex Screw

.....x3

.....x2

94020
3x12mm
Flat Head
Hex Screw

3x12mm

Tighten

Tighten

4mm

.....x3

94042
4mm
Nylon Nut

*Approx. 30.5 mm

1:1

42

3mm
