MS 1b
MICROPHONE STAGE
Features and Specifications
Parameter Specification Limit Units Conditions/Comments
Input Impedance 10k 1% Ω Balanced 5k + 5k
Gain Range 18 to 66 typ. dB
Phantom Power +48 4% V 10 mA max.
..........Impedance 6.81k 1% Ω Each leg
..........Load Regulation 0.1 typ. % 0 to 14 mA
..........RMS CM Noise .003 typ. % % of Vout (10 Hz to 10 kHz)
Max. Input Level +10 / -32 min. dBu Gain 18 / 60, balanced output
Equivalent Input Noise -128 typ. dBu 20 kHz BW, Rs=150 Ω, Gain = 60 dB
Signal to Noise Ratio 96 typ. dB 20 kHz BW, Rs=150 Ω, Gain = 18 dB, re 4 dBu
Dynamic Range 120 / 95 typ. dB Gain 18 / 66
CMRR 80 typ. dB Rs=150 Ω , 120 Hz, Gain = 60 dB
Frequency Response
..........Gain 60 dB
45 to 200k typ. Hz +0, -3dB
..........Gain 18 dB 30 to 200k typ. Hz +0, -3db
THD+Noise (gain 60 dB) .007 (Output=+20 dBu) typ. % 55 Hz to 20 kHz, 20 kHz BW, Rl=10 kΩ
THD+Noise (gain 18 dB) .001 (Output=+20 dBu) typ. % 50 Hz to 20 kHz, 20 kHz BW, Rl=10 kΩ
Line Driver Active Cross-coupled Gain 5.2 / 6 dB typ. unbalanced / balanced
Max. Output Level +22 / +27 min. dBu Unbalanced / Balanced, 2 kΩ load
Output Impedance 50 1% Ω Each Leg
Signal Indicator 2 / 8 typ. dBu Unbalanced / Balanced output, Green LED
Overload Indicator 14 / 20 typ. dBu Unbalanced / Balanced output, Amber LED
Output Cable Length 1000 feet / 300 meters typ. Belden 8451 or equivalent
Unit: Agency Listing
..........120 VAC model
Class 2 Equipment National Electrical Code
UL & CSA Exempt Class 2 equipment
..........230 VAC model CE-EMC EMC directive 89/336/EEC
CE-Safety Exempt per Art. 1, LVD 73/23/EEC
Power Supply: Agency Listing Class 2 Equipment
..........120 VAC model UL File no. E88261
CSA File no. LR58948
..........230 VAC model CE-EMC EMC directive 89/336/EEC
CE-Safety LV directive 73/23/EEC
..........100 VAC model Built to JIS Japan only
Power Supply Input 18 VAC w/center tap 10% Vrms Rane RS 1 supplied
Max Current Consumption 220 mA
Unit Size 1.65"H x 5.1"W x 4.25"D (4.2 cm x 13 cm x 10.8 cm)
..........Weight 1 lb (0.45 kg)
Shipping Size 3.6"H x 11.75"W x 7.2"D (9.5 cm x 30 cm x 18 cm)
..........Weight 4 lb (1.8 kg)
