12. Microphone equalization controls: These three rotary controls adjust the frequency contour of both Microphone Inputs.
They have no effect on any other program material.
13. LOOP ENGAGE switch: This pushbutton controls the Switchable Effects Loop; pressing it to its down and locked
position routes the main signal through the processor attached to the SWITCHABLE LOOP connectors on the rear.
14. MASTER LEVEL fader: This control determines the program and microphone Level at the Main Outputs. Unity gain is
approximately “4.5”
15. BOOTH LEVEL control: Controls the program and microphone Level at the Booth Outputs. Unity gain is approximately
“6.5”. This Output utilizes a “ducking” circuit that reduces the microphone Level when the MIC ENGAGE switch is
activated. See #20, Rear Panel.
16. ZONE LEVEL control: Controls the program and microphone Level of the Zone Outputs. Unity gain is approximately
“6.5”.
17. PROGRAM EQUALIZER controls: These four rotary controls are used to contour the frequency response of the
program at the Main, Booth and Zone Outputs. This is not designed to be the only equalizer in the system, this is intended
to provide EQ between varying program materials.
18. PROGRAM EQUALIZER ENGAGE switch: Engaging this switch enables the Program Equalizer to function. In the out
position, the Equalizer is bypassed.
19. HEADPHONE LEVEL CONTROL: Clockwise rotation of this rotary control increases the headphone drive level.
20. HEADPHONE PAN CONTROL: This rotary control serves two purposes; in the STEREO mode it changes the relative
levels of the Cue and Program mixed together in both earcups. In the MONO mode it changes the balance between the
Mono Cue in the left ear cup and the Mono Program in the right.
21. HEADPHONE CUE mode switch: In the up position, this switch feeds STEREO Program and Cue to both earcups, in the
down position the Headphone circuit provides MONO Cue to the left ear and MONO Program to the right.
22. HEADPHONE output jack: A tip-ring-sleeve stereo jack provides for the insertion of stereo headphones.
23. PEAK PROGRAM METER: This stereo LED bargraph provides a visual indication of program output voltage. The
calibration of the indication is user adjustable. (See #6, Rear Panel.)
Fader Care:
With heavy use in harsh environments, the faders may need lubrication. Rane recommends spraying one or two bursts of
CaiLube MCL into the fader. Work the fader back and forth a few times after spraying. This treatment extends longevity and
can make used faders as good as new.
Order CaiLube MCL ® from:
CAIG Laboratories, Inc.
16744 W. Bernardo Drive
San Diego CA 92127-1904
Phone 619-451-1799
Fax 619-451-2799
Web www.caig.com
