Confirm/Reset Temperature (Factory set at 190ºF)
Manual Dispensing Mode
This feature sets up the CAFEOAT unit to dispense product only as long as the user holds down the selected PUSH button. Once you stop
pressing the dispense button, product stops flowing. Setting the unit for Manual Dispense will turn off the Portion Control Dispense Mode.
Enter Program Mode – Press and hold STOP/WASH for about ten [10] seconds until all lights on the control panel
are blinking.
Set Manual Dispense – While you are in the programming mode, press and hold the selected PUSH button.
Hot water will start to flow.
Continue to hold down the PUSH button until the water stops flowing, then release the button.
Now the selected PUSH button is setup for the Manual Dispensing Mode. The control panel exits the programming
mode.
These features allow you to check the heating tank temperature or change the temperature if desired. The temperature
in the tank is programmable from 80ºF, in 5 degree increments up to 140ºF, then temperature will jump 45 degrees to
185ºF, then resume 2 degree increments up to a maximum 204°F (see Temperature Settings table, right).
Enter Program Mode – press and hold STOP/WASH for about ten [10] seconds until all
lights on the control panel are blinking.
Enter Temperature Program Mode. – Press and hold STOP/WASH for approximately one
[1] second, then release. The current setting will be indicated with the blinking light above the
STOP WASH button.
To Change Temperature – Press and hold the STOP/WASH button again. Each quick flash
increases the temperature. Release the STOP/WASH button when desired temperature is
reached. After releasing the button, the slow blinking light will resume. The new temperature
setting is indicated by counting the number of blinks.
To Set and Exit, press one of the PUSH buttons.
To Change Tank Temperature
3
WATER LEVEL ERROR – 3 LONG AND 1 SHORT
When this code is seen on the control panel, there is a malfunction in the water level control system.
TEMPERATURE SENSOR ERROR – 3 LONG AND 2 SHORT
When this light pattern is flashing on the control panel there is a system failure with the heating tank.
COMMUNICATION ERROR – 3 LONG AND 3 SHORT
This flashing light pattern indicates a communication error between the switch panel on the door and
the power module.
ERROR CODES
Curtis Cafe systems contain various safety features in the electronic circuitry that shut down the functions of the unit in the event of a system failure. Error
codes are signalled by the READY light blinking one of three patterns:
