Wilbur Curtis CBHT - Manual (Page 8)

8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21 WC-5421
WC-3398
WC-37121*
WC-390060
WC-37557*
WC-3422IC
WC-3417*
WC-8559*
WC-66079
WC-61619
WC-3503
WC-5310*
WC-2705
WC-847*
WC-2977-101K
WC-844-101*
WC-37122*
WC-29050*
WC- 895-104*
WC-102
WC-3518* COVER, TOP BREWER
BREW CONE, GOURMET NON-METAL TEA UNITS
KIT, DUMP VALVE LEFT
LABEL, UCM OVERLAY & OUTER CBHT CURTIS ICED COF
KIT, UCM & LABEL CBHT
BREW CONE,ASSY W/SPLASH POCKET TAN ICED COF
BREW CONE ASSY, W/SPLASH POCKET BROWN COFFEE
RELAY, SOLID STATE W/INTEGRATED HEATSINK
SPOUT ASSY , DILUTION PLASTIC
COVER, FRONT
LEG, 3/8”-16 STUD SCREW BUMPER
TUBING, 5/16” ID X 1/8”W SILICONE
FITTING, TEE 1/4” FLARE X 3/8 NPT X 1/4” FLARE PLTD
VALVE, INLET 2 GPM 120V 10W GEN USE YELLOW
KIT,SPRAYHEAD FITTING PLASTIC
VALVE, BY-PASS
KIT, DUMP VALVE RIGHT
SPRAYHEAD, AMBER ADVANCED FLOW
VALVE, DUAL DISPENSE 120V-10W .5GPM x 5GPM
SWITCH, TOGGLE SPST 15A 125VAC RESISTIVE
LEG, GLIDE 3/8”-16 STUD SCREW
DESCRIPTION PART Nº ITEM
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40A WC-37008*
WC-37266
WC-5502-01*
WC-37317
WC-37365
WC-62060
WC-4382
WC-43055
WC-934-04*
WC-1438-101*
WC-522*
WC-5231*
WC-3765L*
WC-29044
WC-5350
WC-53045
WC-43134
WC-810-103
GEM-6 *
GEM-6-101* KIT, TANK LID ROUND
KIT, TANK OVERFLOW FITTING INCLUDES BUSHING
KIT, PROBE, ASSY WTR LEVEL W/FITTING, O-RING & NUT
KIT, STRAIGHT FITTING INCLUDES BUSHING
KIT, TANK INLET FITTING INCLUDES BUSHING
TANK COMPLETE, CBHT 7500W
SHOCK GUARD, HEATING ELEMENT
SHOCK GUARD, THERMOSTAT
KIT, ELEMENT HEATING 2.5KW 220V W/JAM NUTS
SENSOR, TEMPERATURE TANK
THERMOSTAT, HI LIMIT HEATER CNTRL DPST 277V 40A
COMPOUND SILICONE 5 OZ
KIT, INLET VALVE REPAIR USE ON WC-847
SLEEVE, OVERFLOW ASSY GEN USE
TUBE, SILICONE ؽ” ID x ؾ” OD x ⅛” WALL
TUBE ASSY, NYLON BRAIDED ¼” FLARE x 28 ⅛” L
O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
VALVE, CHECK 3/8 X 3/8 BARB SS WITH O-RING & SPRING
FILTER, 500/PKG FOR COFFEE BREWCONE WC-3417
FILTER, PAPER 15x5½X4¾ FOR TEA BREWCONE WC-3398
DESCRIPTION PART Nº ITEM
* RECOMMENDED PARTS TO STOCK
22
23
24
25
26
27
28
29
30
31
32
33
Illustrated Parts – Detail Bubbles
