Illustrated parts – Wilbur Curtis RTB30061 User Manual
Page 6
6
ITEM NO. PART NO.
DESCRIPTION
1
WC-58117
COVER, TOP
2
WC-66079
SPOUT ASSEMBLY , DILUTION PLASTIC
2A
WC-2965
SPOUT, BY-PASS ASSEMBLY (OLDER UNITS)
3
WC-58017-105 COVER, FRONT - DUAL DILUTION
3A
WC-58017-102* COVER, FRONT - DUAL DILUTION (OLDER UNITS)
4
WC-37442*
KIT, UCM & LABEL TCTS-RC
4A
WC- 729-104
CONTROL MODULE, (UCM) 220VAC TEA/COMBO/SWEET TEA BREWERS
4B
WC-39901
LABEL, UCM OVERLAY TCTS DUAL BATCH CURTIS LOGO
5
WC- 889*
VALVE, DUMP LEFT 120VAC12W
5A
WC- 860
VALVE, DUMP LEFT 220V 12W
6
WC-2962-101K KIT, FITTING SPRAYHEAD KYNAR
7
WC-13043-106 HARNESS ASSEMBLY COMPLETE TCTS/T-10600
7A
WC-13044
HARNESS, ASSY TCTS/PTT3-30
8
WC-29025*
SPRAYHEAD, ASSEMBLY AFS-PURPLE
9
WC- 826L*
VALVE, INLET 1.15GPM 120Vac 10W
9A
WC- 856
VALVE, INLET 1 GPM 240V 10W
10
WC-8556*
HEATSINK and TRIAC ASSEMBLY 40A 600V
11
WC- 895-104* VALVE, DUAL DISPENSE 120V-10W .5GPM x .5GPM
11A
WC- 878-104
VALVE, INLET DUAL 240V 10W .5GPM X .5GPM
12
GEM-6-101*
FILTER, PAPER 15 X 5-½” ALTRA 4-3/4” H
13
WC-43134
O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
14
WC-5853-102 COVER, TOP HEATING TANK
15
WC-43062*
GASKET, TANK LID
16
WC-5502-01*
KIT, PROBE, ASSEMBLY WATER LEVEL W/HEX FITTING, O-RING & NUT
17
WC-6277*
TANK, COMPLETE 1600W 120V TCT
17A
WC-6290-101 TANK, COMPLETE D500GT/TCTS PTT3/CBS w/WC- 934-101 ELEMENT
18
WC- 904-04*
KIT,ELEMENT, HEATING 1.6KW120V W/ JAM NUT & SILICONE WASHERS
18A
WC- 934-04
KIT,ELEMENT HEATING 2.5KW 220V W/ JAM NUT & SILICONE WASHERS
19
WC-1438-101* SENSOR, TEMPERATURE TANK
20
WC-4394
GUARD, SHOCK/HEATING ELEMENT
21
WC- 523*
THERMOSTAT, MANUAL RESET 120/240VAC 25A 220ºF MAX
21A
WC- 522
THERMOSTAT, HI LIMIT HEATER CONTROL DPST 277V 40A
22
WC-2707
TEE, 1/4 FLARE x 1/4 FLARE x 3/8 NPT BRASS
23
WC-53038
TUBING, NYLON BRAIDED 1/4” FLARE x 11-1/8” LG. FLEXIBLE
24
WC-37255*
KIT, DUAL VALVE WATER INLET
25
WC-5310*
TUBE, 5/16 ID x 1/8W SILICONE
26
WC- 102*
SWITCH, TOGGLE SPST 15A 125Vac RESISTIVE
26A
WC- 103
SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC RESISTIVE
27
WC-3518*
LEG, 3/8”-16 x 1/2” LG. GLIDE
28
WC-8531-101* RAIL, BASE
29
WC-3503*
LEG, 3/8”-16 STUD SCREW BUMPER
30
WC-3396-101* BREW CONE ASSEMBLY BLK ROTATING NON-METAL - STD TEA
Illustrated Parts
* RECOMMENDED SPARE PARTS
