2
SPRAYHEADS: Mentioned in this Programming guide are the words Gray and Purple. This refers to the color of the spray-
head. The current sprayhead is the purple AFS. The older version is the gray sprayhead. See the illustration at right.
PURPLE
GRAY
To Access Programming
Turn off (dark display) by pressing ON/OFF button (yellow). Press and hold BREW button #4 and then press and release ON/OFF button (yellow).
Continue holding the #4 button. Display will read , wait until is displayed Enter the 4-digit access code, the digits 1-4 corre-
spond to the buttons (see illustration below).
The default code set at the factory is 1-2-3-4. Then will be displayed.
All programming selections are performed with the three center buttons.
The symbols below the buttons are:
Scroll LEFT
 SELECTION or ENTER to save new parameter
Scroll RIGHT
4 3 1 2
Your Curtis Generation 3 Brewer is Factory Pre-Set for Optimum Performance.
After connection to water and power; the rear toggle switch must be on. You will hear a beep sound, indicating power is available to the controller.
The control displays . Press ON/OFF button and the screen will display . After three seconds, is displayed.
Water will fill the tank (approximately 2-3 minutes depending on water flow rate). When the proper level is reached will appear on the
screen. It takes approximately 20 minutes to reach set point temperature of 204°F.
Control will display when temperature reaches the set point (204°F). Unit is now ready to brew.
CURTIS < TCT-RC >
CURTIS
CURTIS
FILLING
CURTIS
HEATING
CURTIS
READY to BREW
1. Brewer should be ON (Confirm at rear toggle switch, then press ON/OFF button) and Ready-to-Brew displayed.
2. Make sure tea containers are in place, sitting on the brew deck.
3. Place a paper filter in
the brew basket. Pour
leaf tea into the filter.
Place the filter into the
brew cone.
4. Slide brew cone into
brew rails.
6. Press the desired brew
button on the UCM
control panel. The brew
cycle will start.
5. Select the tea container
you wish to brew into
and rotate the brew
cone to direct the flow
into that tea container.
Tea Brewing Instructions
CAUTION HOT LIQUID, Scalding may occur. Allow the brew cone to completely drain before removing.
