Wilbur Curtis TBS - Manual (Page 7)

7
13
14
14A
15
15A
16
16A
17
18
18A
19
20
20A
21
22
23
23A
24
25
26
26A
27
28
29
29A
30
WC-37255
WC-889 *
WC-860 **
WC-102*
WC-103**
WC-3518
WC-3503
WC-8531
WC-5853-102
WC-5851
WC-43062
WC-6277
WC-6290-101**
WC-5231*
WC-5502-01*
WC-904-04*
WC-934-04**
WC-4394
WC-1438-101*
WC-523*
WC-522 **
WC-5310*
WC-810-103
WC-895-105
WC-878-102**
WC-43134
KIT, DUAL VALVE WATER INLET
VALVE, DUMP LEFT 120V 12W
VALVE, DUMP LEFT 220V 12W
SWITCH, TOGGLE SPST 25A 125/250VAC RESISTIVE
SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC RESISTIVE
LEG, GLIDE 3/8”-16 STUD SCREW
LEG, 8-32 STD SCREW BUMPER
RAIL, BASE TCTD
COVER, TOP HEATING TANK GEN USE
COVER, TANK W NOTCHES (OLDER UNITS)
GASKET, TANK LID
TANK, COMPLETE 1600W 120V
TANK, COMPLETE TCTS/ PTT3 /CBS/W/WC- 934-01 ELEMENT
COMPOUND SILICONE 5 OZ
KIT, PROBE, ASSY WATER LEVEL W/HEX FITTING, O-RING & NUT
ELEMENT, HEATING 1.6KW 120V W/JAM NUTS
KIT,ELEMENT HEATING 2.5KW 220V W/JAM NUT & WASHERS
SHOCK GUARD, HEATING ELEMENT
SENSOR, TEMPERATURE TANK
THERMOSTAT, MANUAL RESET 120/220V 25A 220ºF MAX
THERMOSTAT, HI LIMIT HEATER CONTROL DPST 277V 40A
TUBING, 5/16” ID X 1/8” W SILICONE
VALVE, CHECK 3/8 X 3/8 BARB SS WITH O-RING & .010 SPRING
VALVE, INLET DUAL 120V 10W 2 GPM X .5 GPM
VALVE, INLET DUAL 220V 10W 1.0 GPM TANK X .5GPM DILUTION
O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
* RECOMMENDED PARTS TO STOCK
** 220V COMPONENTS
DESCRIPTION PART № ITEM №
PARTS LIST
ROUGH-IN DRAWING
