Wilbur Curtis TBS - Manual (Page 5)

5
Programming
Error Message
With G3/Gold Cup Series brewers, there are three error messages that can appear on the screen to advise the user
of a malfunction. If one of these error messages appear, the brewer will lock up and stop functioning until the error is
corrected.
An error message will occur under the following conditions:
1. Water level fill error or overflow. This error message occurs when the inlet valve solenoid has
been on for more than 10 minutes. This error message also occurs when the valve is refilling
the tank during a brew cycle for more than 1½ minutes.
2. Water temperature control system error. An open probe or a break in the temperature control
circuit is detected.
3. Excess temperature. The temperature sensor is reading that the temperature in the heating
tank has risen above 210ºF.
The screen may display a phone number to call for service. After the malfunction is corrected, the
error message must be cleared. To reset the control panel and return to normal operation, press
 for 5 seconds.
(800) 000-000
Sensor Err
(800) 000-000
Water Level Err
Tank Temperature Check
Turn on brewer at the control panel ON/OFF button. Press and hold ƒ button (see illustration, page 3) for 5 sec-
onds. Water Temperature will be displayed (temperature in heating tank).
(800) 000-000
Over Temp Err
Exit
Display Brew Time (Factory set to ON)
Press  to Select. Pressing < or > toggles between ON and OFF.
Display Messages (Factory set to ON)
Press  to display ON or OFF. Pressing either < or > toggles between on and off. This feature allows the operator to
select the message “Rinse Server Before Brewing”. This will be displayed any time the unit is not brewing.
Model Select (Factory set to TEA/IC-1BATCH)
Press  to select, < or > to select model. The selections are: TEA/IC-1BATCH, TEA/IC-2BATCH, TEA/1C-3BATCH,
TEA/IC-4BATCH, TEA-SWEET, DUAL DILUTION, DUAL-SWEET, COMBO, COMBOSWEET. Press  to set. When
the Model Select feature is changed, all settings are reset to the defaults of the newly selected model.
Exit
Press  to select, exits program mode and returns unit to operation. Pressing > returns you to Tea Recipes.
Display Brew
Time
Model Select
Display Messages
