Wilbur Curtis TBS User Manual
Page 3
3
SPRAYHEADS: Mentioned in this Programming guide are the words Gray and Purple. This refers to the color
of the sprayhead. The current sprayhead is the purple AFS. The older version is the gray sprayhead. See the
illustration at right.
PURPLE
GRAY
To Go Into Programming
Turn off (dark display) by pressing ON/OFF button (yellow). Press and hold BREW button 4 (green) and then press and release ON/OFF but‑
ton (yellow).
Continue holding BREW button. Display will read
, wait until
is displayed Enter the 4‑digit access code, the
digits 1‑4 correspond to the buttons (see illustration below).
The default code set at the factory is 1‑2‑3‑4. Then
will be displayed.
Program Menus
All programming selections are performed with the three center
buttons. The symbols below the buttons are:
Scroll LEFT
SELECTION or ENTER to save new parameter
Scroll RIGHT
4
3
1
2
Continued on Page 3
Program Menus
Tea By Volume
Recipes
Tea By Time
Program Menus screen. Press > button, to show the next menu item.
Recipes (Factory set to Standard Tea Purple)
Press to Select. Press < or > to scroll through recipes: Standard Gray, Standard Purple, Tropical Gray, Tropical
Purple, 76/308 Gray or 76/308 Purple. Press to set.
Tea Dilut Volume
Tea Dilut Delay
Tea Dilut Time
Tea by Volume: Press to select, Display will now show Push START To Begin... Press the BREW button then hot
water starts running, when desired volume is reached press BREW button again to stop the flow. Now the volume
has been set. Pressing > button will display the subsequent menu features.
Tea by Time (Factory set to 5:52)
Press to select. By pressing < or > buttons, you can increase and decrease time. Press to set minutes and
seconds. Units with the half batch option, the Half Batch brew button is factory set at for half the brew time (2:56).
Tea Dilution Delay (Factory set to 0:30)
Press to Select. Press < or > buttons, to add or decrease time. Press to set.
Tea Dilution Volume: Press to Select, Display will now show Push START To Begin... Press the BREW button
and water will flow, when desired volume is reached press BREW button again to stop the flow. Now the volume has
been set. Press > to display subsequent menu features.
Dilution Time (Factory set to 4:05)
Press to Select. By pressing < or > buttons, you can increase and decrease time. Press to set minutes and
seconds.
Tea Dilution Stir (Factory set to ON).
Press to Select. Press < or > buttons, to toggle between OFF and ON. Press to set.
Tea Pulse Brew (Factory set to OFF).
Press to Select. Press < or > to select ON, OFF or D. D is a manual adjust from 1 to 20 pulses with an ON time
from 5 to 150 seconds and an OFF time from 5 to 150 seconds.
Tea Fast Brew (Factory set to OFF).
Press to Select, press < or > to choose ON or OFF. Selecting ON will start hot water spraying in the brew cone
first and then 1 minute later the dilution water will start to flow.
Tea Dilut Stir
Tea Pulse Brew
Tea Fast Brew
