Removal and replacement procedures – Compaq P 110 User Manual
Page 65
Maintenance and Service Guide
5–1
5
Removal and Replacement
Procedures
This chapter provides removal and replacement procedures.
All screws removed during disassembly are P0 Phillips screws.
There are four different sized screws that must be removed and
replaced when servicing the computer. Make special note of the
size and location of each screw during removal and replacement.
Refer to Appendix C, “Screw Listing,” for detailed information
on screw sizes, locations, and usage.
