Final Assembly
IMPORTANT
Please consult your Crystal
Fire instruction manual for
detailed instructions and
important information
related to hooking up your
CF-1224 burner, including
safety information, proper
tightening of connections
with two wrenches and full
burner setup and lighting
instructions.
DO NOT ATTEMPT TO
INSTALL CF-1224 BURNER
WITHOUT FIRST
CONSULTING THE
MANUAL. IF YOU ARE
UNSURE OF HOW TO
COMPLETE THE STEPS
OUTLINED, CONSULT A
QUALIFIED TECHNICIAN
WARNING
After consulting the
manual and following
instructions, remember;
before operating, all gas
connections must be fully
checked for leaks
With your Sonoma fireplace in the
desired location, drill a small hole
large enough for incoming gas line to
pass through in a side, back, or bottom
of the fireplace, depending on
installation location.
Carefully slide firebox back into the
unit. Slide forward until the back
surface of the fire box meets the front
stucco surface of the fireplace body.
Have a qualified licensed professional
make all gas connections at this time.
This should be done in accordance
with local and national codes.
Slide the hearth pad into place
carefully and evenly. If fit is too tight,
lift firebox slightly while another
person slides hearth pad into the unit.
Install gas burner by gently lowering
into the cutout provided.
Install Logs and accessories as detailed
in the provided instructions for those
products.
