Outdoor Great Room Providence Fire Pit User Manual
Page 6
6 |
P a g e
5. Set burner into place with the igniter at the
opposite end from the door of the fire pit. See the
section labeled Gas Connection and Igniter
Installation to install gas lines and piezoelectric
igniter , then set the metal top into place on TOP of
the burner.
6. The underside of this top has two screw holes.
Rotate the top to match these up with the
previously installed tab, set the top onto the base,
and slide the mounting bracket up and under the
lip of the powdercoated top. Line up screw holes
and insert two screws at shown.
NOTE: Do not
attempt to lift or
carry fire pit by its
top. Always lift
from the base!
