Table of Contents
1. Listing and Code Approvals
a. Appliance certification
b. BTU specifications
2. Getting Started
a. Design and installation considerations
b. Tools and supplies required
c. Inspection of appliance and components
d. Step-by-step lighting instructions
3. Framing Clearances
a. Selecting a location
b. Required clearance to combustibles
c. Framing an enclosure for LP supply system
4. Fuel Information
a. Fuel
b. Gas pressure
c. Gas connection
d. LP Gas supply
5. Appliance Setup
a. Burner assembly
b. Glass installation
6. Operating Instructions
a. Before lighting
b. Lighting the fire
c. After the fire is lit
7. Finishing
8. Converting to Natural Gas
9. Troubleshooting
10.Maintaining and servicing the appliance
11.Reference Materials
a. Service parts list
b. Limited one-year warranty
c. Contact information
CF20

20” Round burner

Black propane hose
with regulator

Flexible metal gas line

Ball valve

Piezoelectric igniter

#43 Orifice (LP)

#31 Orifice (NG)

2 bags of decorative
glass
CF-1224

12”x24” burner

Black propane hose with
regulator

Flexible metal gas line

Ball valve

Piezoelectric igniter

#43 Orifice (LP)

#31 Orifice (NG)

2 bags of decorative glass
CF-2424 , CF1242

24”x24” OR 12”x42” burner

Black propane hose with regulator

Flexible metal gas line
 Ball valve

Piezoelectric igniter

#36 Orifice (CF2424 only- home LP)

#31 Orifice( CF1242 only- Home LP)

#43 Orifice (20lb LP)

#17 Orifice (CF2424 only- NG)

#21 Orifice (CF1242 only -NG)
 4 bags of decorative fire glass

Remote *

U-shaped heat shield bracket (used for
remote operation installs only)
(*Included with remote-operated unit only)
What’s included…
