Recommended Lubricant
American Oil Co., Rykon #2 EP, or Chevron BRB #2, or other
comparable lithium base lubricant with a temperature range of 300°F.
Eccentric Weight Adjustment
All Metalfab Vibratory Motors feature eccentric weights to change the
amplitude and centrifugal force. The following procedure should be
adhered to whenever the eccentric weights are adjusted.
1. Remove the eccentric weight covers on both ends of the motor.
2. Note the present eccentric weight setting.
3. Loosen the bolt holding the eccentric to the shaft.
4. Line up the desired number on the eccentric with arrow on the
shaft.
5. Tighten the weight adjustment bolt and duplicate this process on
the other side of the motor.
Note: The upper and lower eccentric weights must be set
at the same number.
WARNING: Before any adjustments, vibrator should be
electrically “LOCKED OUT”.
Eccentric Weight Settings
FORCE IS IN POUNDS VIBRATOR
SIZE 1 2 3 4 5 6
4P-0.7K 0 220 510 570 670 700
4P-2K 230 660 1200 1740 1920 2000
4P-5K
*HIGH
1500 2100 3200 4200 4860 5100
**LOW 300 1000 1875 2625 3000 3200
