53

INITIAL OPERATION AND TESTING OF CONTROLS (INSTALLER ONLY)

1. Turn on power to the water heater and fully open a hot water tap.

2. Check the operation of the water heater. Check the operation of the remote temperature

control(s). Check the operation of the power failure protection system (drain solenoids).

3. Explain the proper operation of the new Bradford White EverHot

water heater to the end user.


Troubleshooting – Electrical

There are a number of (live) tests that are required when fault finding this product. Extreme care should
be used at all times to avoid contact with energized components inside the water heater. Only trained
and qualified service technicians should attempt to repair this product. Before checking for resistance
readings, disconnect the power source to the unit and isolate the item from the circuit (unplug it).

Table 14.

(SV1, SV2, SV3, SV4, and POV) Gas Valve and Modulating Solenoids (Set Meter Above 2k).

Wire Color

Voltage

Resistance

Connector

No.

Pin

Nos.

(SV0) Pink-Black

11-13 VDC

37-43 ohms

B5

7-8

(SV1) Blue-Black

11-13 VDC

37-43 ohms

B6

6-7

(SV2) Yellow-Black

11-13 VDC

37-43 ohms

B7

5-7

(SV3) Red-Black

11-13 VDC

37-43 ohms

B3

4-7

(SV4) Orange-Black

11-13 VDC

37-43 ohms

B4

3-7

(POV) Orange-Orange

2-15 VDC

67-81 ohms

B2

10-11

Table 15.

(M) Water Flow Control Device Servo.

Wire Color

Voltage

Resistance

Connector

No.

Pin

Nos.

Red or Pink-Orange

5-7 VDC

n/a

G2

3 or 4-

8

Blue or White-

Orange

5-7 VDC

n/a

G2

1 or 2-

8

Red-Pink n/a

30-50

ohms

G2

3-4

Blue-White n/a 30-50

ohms G2

1-2

Gray-Yellow 0-6

VDC

n/a

G2 7-5

Gray-Brown 0-6

VDC

n/a

G2 7-6

Note: The grey wire listed above turns to black at F connector on the PCB.

Table 16.

(QS) Water Flow Sensor.

Wire Color

Voltage

Resistance

Connector

No.

Pin

Nos.

Black-Red 11-13

VDC

n/a

E5 1-3

Yellow-Black

4-7 VDC

1-1.4 Mega ohms

E5

2-3

Table 17.

By-pass Flow Control.

Wire Color

Voltage

Resistance

Connector

No.

Pin

Nos.

Brown-White

2-6 VDC (unit

in operating

mode)

15-35 ohms

G1 1-5

Orange-White G1

2-5

Yellow-White G1

3-5

Red-White -

Ground

G1 4-5
