Connections
EC3
Inputs
1
9
Door
Filter Door
Sail Switch
Overload
NC
NC
NC
24VAC
24V Neutral
EC1
Outputs
1
12
Blower Clean
NC
Common
FWD
Dir Common
REV
Blower
Heat Call
NC
Dryer Busy
NC
NC
1 24VAC
24V Neutral
EC4
Power
EC2
Temp Probe
1 Blue Wire
White Wire
Red Wire
NC
NC
NC
NC
2
13
