Wall installation
1. Using a level, locate where panels will hang. Place the panel on the wall and use a pencil to mark foam block
locations on the wall.
2. Remove product from wall and drill holes. Then insert plastic anchors.
3. Place foam blocks on wall and screw in place.
4. Fit panel over foam blocks. Finish by placing wooden inserts over foam blocks within the wells.
Ceiling installation
1. Drop panels into empty ceiling grid.
WaveLens
™
WaveLens
™
Installation Guidelines
