ASSEMBLY / USER GUIDE

ProGO Installation Guides.indd (July 25, 2013 10:41 AM)

Thank you for purchasing the

Auralex

®

ProGO-26 - 44 Caster Kit.

ProGO-44: Using the supplied wood screws install the casters as shown

below with a locking caster at the outboard end of the base.

Duplicate this caster installation for the other base in the pair.

ProGO-26 Caster Kit (one base required)

(2) Locking casters

(2) Non-locking casters

(16) #10 x ¾” wood Screws

ProGO-44 Caster Kit (two bases required)

(2) Locking casters
(4) Non-locking casters
(24) # 10 x ¾” wood screws

ProGO-26

& ProGO-44

Caster Kit

TOOLS NEEDED: #2 Phillips screw driver. A power driver with adjustable clutch is recommended. Start with a lower

clutch setting to avoid stripping screw heads or the wood panels!

Outboard end

Inboard end

Outboard end of base with two casters

Inboard ends of bases

with single casters

NOTE the five sets of pre-drilled caster mounting holes on the bottom of

the ProGO base

ProGO-26: Using the supplied wood screws, install the casters as shown

below with a locking caster at each end of the base
