Auralex Pro Plus Roominator Kit - Manual

Roominator Performance Series ™
USER GUIDE
Auralex ® Acoustics, Inc.
1-800-959-3343 / 317-842-2600 / Auralex.com
9955 Westpoint Drive, Suite 101, Indianapolis IN USA 46256
EACH KIT INCLUDES:
INSTALLATION:
Project ➋ ™
(24) 2’x2’x2” Studiofoam ® Wedge
(8) LENRD ® Bass Traps
(128) EZ-Stick Pro ™ Tabs
Deluxe Plus ™
(24) 2’x2’x2” Studiofoam ® Wedge
(8) LENRD ® Bass Traps
(6) T’Fusor ™ Diffusors
(152) EZ-Stick Pro ™ Tabs
Pro Plus ™
(36) 2’x2’x2” Studiofoam ® Wedge
(12) LENRD ® Bass Traps
(8) T’Fusor ™ Diffusors
(224) EZ-Stick Pro ™ Tabs
STUDIOFOAM ® WEDGE
T’FUSOR ™
LENRD ® BASS TRAP
EZ-STICK PRO ™
Studiofoam Wedge, LENRD Bass Traps and T’Fusor Diffusors can be
mounted to standard drywall with the included
EZ-Stick Pro Tabs. Be advised
that the EZ-Stick Pro Tabs are designed for permanent installations and will
damage drywall and painted surfaces when removed.
Mark the target position on your wall or ceiling where the product will be
mounted using small pencil marks, pieces of masking tape or any similar non
marring method. Be sure the surface where the
EZ-Stick Pro Tabs will adhere is
free of dirt, dust or other oily contaminants by spot cleaning with rubbing alcohol.
Studiofoam Wedge Panels, LENRD Bass Traps and T'Fusor Diffusors use
4
EZ-Stick Pro Tabs each.
Remove one of the release layers on the EZ-Stick Pro Tabs and affix it to
the rear side of the products perimeter, usually near the corners. Apply firm
pressure and wait about 5 minutes for the adhesive to set. Remove the second
layer of the release paper from each of the
EZ-Stick Pro Tabs, carefully orient
the panels position prior to contact with the wall, then press in place with
moderate pressure.
