1. HARDWARE AND CONNECTORS
SoundGrid Ports 1-3 (Ethernet) connect the SoundGrid Network.
Status LED: SoundGrid Ports 2 and 3 have a network activity led only. Only SoundGrid Port 1 has a Gigabyte connection indicator.
Colors and respective status are as follows:
SoundGrid Ports 2 and 3:
■ Link/Act Led = flashing amber
SoundGrid Port 1:
■ Link/Act Led = flashing green
■ GigE (Gigabyte Connection Indicator) = solid green
Gigabyte Connection Indicator
Network Activity Led
Network Ports
