Allen&Heath W21442-SL1 User Manual
Wz14:4:2, Allen & heath, Sys-link expander option
Publication AP3664
MixWizard Series
WZ14:4:2+
FITTING INSTRUCTIONS
For information on using SYS-LINK please refer to APPLICATIONS NOTE AP3665
SYS-LINK
EXPANDER OPTION
This option connects a MixWizard WZ14:4:2+ as a channel expander to a second
A&H console already fitted with SYS-LINK with just one or two interconnecting
cables.
Interconnecting cables not supplied.
Issue 2 July 01
Kit Part No:
W21442-SL1
Single option to install SYS-LINK to one MixWizard WZ14:4:2+ unit to
allow interconnection to a second console already fitted with SYS-LINK.
