4. WORKING WITH TWO M-WAVES CARDS
You can use M-Waves V1 and V2 Cards in the same setup. The only limitation is that a first-generation M-Waves card, an M-Waves V1,
cannot be an Ethernet clock (SoE) slave. It must provide clock sync to a second-generation card, an M-waves V2. Setting up the clock
master for the network is done in either MultiRack SoundGrid or SoundGrid Studio applications.
In the Waves SoundGrid Inventory window, assign the two M-Waves cards to 1 and 2 consecutively. Select the one you want to be
the master under the Master column.
To synchronize the two M-Waves cards, choose one of the following two options:
1. If you want the iLive system to be the source (Internal):
(a) On the iLive system, set Audio Clock Source to Internal.
(b) In the SoundGrid Inventory window, click on the Settings for the
M-Waves V2 card assigned to 1, and set it to Digital.
(c) Click on the Settings for the M-Waves V2 card assigned to 2.
It will be set automatically as Slave and the source will automatically
be synced over Ethernet.
