If the Wizard cannot locate the requested SoundGrid network devices, this means you may have chosen an incorrect network port
on your computer. Check the physical connections and then click SCAN. When configuration is complete, close the window. If there
is still a problem, you can configure your system manually. Use the System Inventory page to assign devices, control the network,
and manage clock. To learn how to use this page, please refer to the user guides for SoundGrid Studio and StudioRack.
The first device added to a rack is designated as the Sync-over-Ethernet clock master and is placed in the first rack slot.
A populated device slot displays the mode, clock status, and sample rate of the I/O. The clock master device is indicated by its blue
color and the icon text: On, Master Clock, INT (48 kHz).
