Large, outdoor yr (16.5"), Visor and non-visor – Cooper Lighting ADY071447 User Manual
Page 2
"
5
7
149.35
15.88
"
8
8
5
7
15
16 "
201.49
Installation Instructions
Vault w/ visor
C-Scroll w/ visor
Roundel w/ visor
These installation instructions are valid with the above Ametrix styles
Mounting Plate Dimensions In [mm]
Lamping Size Chart
(lamps provided by others)
Warning
: Before starting any work ensure
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Large, OUTDOOR
YR (16.5")
(Yoke mount, Remote ballast)
Visor and Non-Visor
Sheet 2 of 2
ADY071447 Rev A (ECN070295)
CL
Mounting dimensions are for 16 1/2"(419.1mm) large YR indoor only
11
3
4 "
298.70
"
1 4
1
31.75
23.24
29
"
32
9
32
"
6.93
FIXTURE SIZE
(inches/ mm)
WATTAGE
# OF
LAMPS
LAMP TYPE
LAMP DESCRIPTION
Lamp
(not to scale)
16
1/2
/ 419.1
32 W
1
T4
Compact Flourescent
16
1/2
/ 419.1
42 W
1
T4
Compact Flourescent
16
1/2
/ 419.1
57 W
1
T4
Compact Flourescent
16
1/2
/ 419.1
100 W
1
ED17
Ceramic Metal Halide
16
1/2
/ 419.1
150 W
1
T6
Ceramic Metal Halide
16
1/2
/ 419.1
175 W
1
ED17
Ceramic Metal Halide
