Cooper Lighting AMETRIX P1R - Manual (Page 2)

Warning
Visor and Non-Visor
Sheet 2 of 2
Installation Instructions
Vault w/ visor C-Scroll w/ visor Roundel w/ visor
(lamps provided by others)
Lamping Size Chart
These installation instructions are valid with the above Ametrix styles
: Before starting any work ensure
Mounting Plate Dimensions In [mm]
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Small, OUTDOOR
P1R
(Pendant, 1-way, Remote ballast)
ADY071467 REV B(ECN80481)
Use only GE or Sylvania
CFL lamps
Side View Top View
7
16 "
11.42
on order
Length dependant
5"
127
127
5"
1
12.70
101.60
4"
101.60
4"
25.40
1"
2 "
25.40
1"
6.35
(4x)
1
"
4
1
2 "
12.70
FIXTURE SIZE
(inches/ mm)
WATTAGE
# OF
LAMPS
LAMP TYPE LAMP DESCRIPTION
10 3/4 / 273.05 39 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 70 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 150 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 26 W 1
4-Pin Triple
Tube
Compact Fluorescent
12 3/4 / 323.85 32 W 1
4-Pin Triple
Tube
Compact Fluorescent
12 3/4 / 323.85 42 W 1
4-Pin Triple
Tube
Compact Fluorescent
10 3/4 / 273.05 100 W 1 T4 Halogen (Single Ended)
12 3/4 / 323.85 150 W 1 T4 Halogen (Single Ended)
12 3/4 / 323.85 250 W 1 T4 Halogen (Single Ended)
LAMP
(not to scale)
