5
Push the colour cartridge home make sure the catch is closed Now push home the Black cartridge
and close the lid.
Make sure the tubes are exiting between the ‘Colour’ lid and the ‘Black’ lid
Push the printhead all the way to the left
of the printer.
Hold the centre clamp central to the black vertical line and make sure all the
slack tube is taken up (without pulling the printhead from the left). If there
is too much slack or you have to move the printhead to get the centre clamp
in the correct position then slide centre clamp on the tube until you achieve
the desired amount as shown.
Peel off backing and fix centre clamp
firmly in position as shown
Assemble the small tube clamp onto the tube and fix onto the printer as
shown.
