Subli-Print Bulk Feed Installation
4
Make sure you have all the relevant parts with
your system.
These include:
1.
1 x Pre-filled cartridge, tube and bottle
assembly.
2. 2 x replacement cartridge lids.
3. 1 x bag containing 6 filter caps and
small tube clamp.
4. 1 x Disk containing ICC profile and
instructions.
5. 1 x Syringe
6. 5 x bottles of spare ink (40ml each)
7. 1 x Centre clamp support
Press yellow button and remove power lead as cartridge moves to the left. This
will allow the cartridge to be positioned freely by hand.
Remove original lids and any
cartridges
Fit the replacement lids supplied. Place cartridges gently into position
but do not press down yet
Remove the rubber stoppers and
replace with the supplied filter caps
1
2
3
4
5
6
7
