Remove the backing tape and firmly press
the small tube clamp in place as shown.
Remove the backing tape from the black
clamp on the tubes and fit it to the tube
support as shown.
With the printhead position as far left as
possible check that the tubing is not too
tight or slack.
Move the printhead as far to the right as
possible and also check the tubing.
If the tube is too tight in either position it
can be adjusted by sliding the tube
through the black tube clamp on the centre
tube support (this is quite stiff as it is
designed not to slip during normal use).
