Place the bottles to the right of the printer
as shown.
NEVER PLACE THE BOTTLES
HIGHER THAN THIS
(If the bottles are placed higher then the
ink may siphon into the bottom of the
printer.)
Make sure there are no twists in the
tubing.
Place cartridge unit into printer and push
down lid firmly.
The tube support will be fixed 225mm
(8
? ”) from the edge of the printer
housing as shown.
Remove the tape from the sticky pads and
firmly press the tube support into place.
Page 3
