44 VRC System Operators Guide
Shot status colour codes
Shots stored on the grid display are colour coded to indicate the shot status (Figure 22).
Figure 22 Shot status colour codes
Table 2: Shot status colours
Frame Colour Description
Red background Indicates that the camera is moving (via Cut or Fade) to the shot. See Fusion-1
target shot in Figure 22.
Yellow banner across the frame
corner Indicates that this is the last shot selected. See Fusion-1 target shot in Figure 22.
Green background Indicates that this shot is cued and the camera will move to this shot when you
select Cut or Fade. See Fusion-4/44 shot in Figure 22.
Dark blue background Indicates that the camera is ‘exactly’ on shot as stored in the show file. See
Fusion-3/3WX STAND END shot in Figure 22.
Purple background Indicates that this is a Sequence currently selected for play.
Light blue background Indicates that the camera has been trimmed off shot away from the shot stored in
the show file. See Fusion-2/2K shot in Figure 22.
