Vinten Radamec HS-105P Pan & Tilt Head User Manual

Page 16

Text mode
Original mode

Operators guide

[12] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Three-hole mounting plate
[13] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Serial label

Fig 3 HS-105 pan/tilt head underside

[12]

[13]

This manual is related to the following products:

HS-105PE Pan & Tilt Head
