HS-105P pan and tilt head
14
[8] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Main cover fixing screws (7 off)
[9] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cover plate (studio models only)
[10] . . . . . . . . . . . . . . . . . . . . . . . Image Tracker Unit (option available on all HS-105 models)
[11] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Desiccant storage box (environmental models only)
Fig 2 HS-105 pan/tilt head main cover
[10]
[11]
[8]
[9]
