Installation Manual V1.4.4
Page 15 of 46
Makedef.exe will create the name.mkr file for you to edit with rough
estimations of each target position. This file is essentially a text file and can
be edited in Notepad or alternatively in Freed_v14.exe in:
Utilities
Edit Target Data (Alt-U-E)
Enter the target numbers according to the target map. If there is no target
then enter “????” for the target ID. If major changes in positioning are
necessary, but target numbers have already been entered, global changes
(x, y, z or rotation) can be made to the name.mkr file in Freed_v14.exe in:
Utilities
Change Coordinates (Alt-U-C)
Note: always keep a backup of the original name.mkr file in case a restart
is required.
Example .mkr file generated by
makedef.exe
Example .mkr file after system
calibration
Enter target ID
X
Y
Z
positions in metres as generated by makedef.exe
