Installation
Rear Panel Data Connections
Power Connections
Powering Up
Before powering up, ensure that all external cable connections have
been secured correctly.
To power up, connect
the AC adaptor to the
power supply. The
power indicator LED
on the Ci box will
illuminate.
RS232/422 serial data
connections to compatible
robotic heads and camera
control units
