MultiController II Installation
3-16 User Manual
Head Type Cofiguration
The following table lists the configuration choices available:
Proportional/Fixed Speed
In Proportional mode, the pan and tilt speed in response to joystick motion is
dependent on the current zoom angle. Therefore, when you are zoomed in tight,
pan and tilt move more slowly thatn when you are zoomed out wide. Choose the
mode that you feel most comfortable with and set all heads the same.
HS-102
Two baud rate choices (2,400 and 19,200) are provided for the HS-102. Make
sure that you select the baud rate that matches the setting in the head itself. Refer
to the HS-102 User Manual for information on setting the baud rate in the head.
HS-105
Two baud rate choices (2,400 and 9,600) are provided for the HS-105. The nor-
mal selection for the HS-105 is 2,400 baud unless you have a custom version of
the head. Contact your Vinten representative if you are uncertain.
HS-2010
Use the HS-2010 selection if you are using either the HS-2010MH head or the
HS-2010R head.
Config Code Head Types Baud Rate Pan/Tilt Speed
00 HS-105, HS-102 2,400 Proportional
01 HS-2010 9,600 Proportional
02 HS-105 (custom) 9,600 Proportional
03 HS-102 19,200 Proportional
16 HS-105, HS-102 2,400 Fixed
17 HS-2010 9,600 Fixed
18 HS-105 (custom) 9,600 Fixed
19 HS-102 19,200 Fixed
